STB-18CNC-4A-2S Electric Cnc Tube Bending Machine
STB-18CNC-4A-2S Electric Cnc Tube Bending Machine
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Description
The body is made through welding, the mechanical part through assembly; using imported hydraulic system and electronic control system.
1. Fully automatic and CNC pipe bending machine;
2. Equipped with 4 programmable axis;
3. Feeding: servomotor drive with the ball screw; Rotation: servomotor drive with reducer.(the servomotor from Mitsubishi); Head left and right: servomotor drive with ball screw
4. Bending: Servomotor bending with reducer; accuracy ± 0.05°.
5. Premium hydraulic part with professional hydraulic system design.
6. Automatic lubrication system for moving areas.
7. Self-diagnostic system, detecting the error immediately.
8. Multiple groups pipe-bending information storage;
9. Industrial PC (windows system) assorted with touch screen display, 3D preview, remote control, D bending simulation, collision prevention.
10. Electric cabinet cooling fan and the hydraulic cooling system ensure the equipment long-time work stably under the high temperature.
1. Fully automatic and CNC pipe bending machine;
2. Equipped with 4 programmable axis;
3. Feeding: servomotor drive with the ball screw; Rotation: servomotor drive with reducer.(the servomotor from Mitsubishi); Head left and right: servomotor drive with ball screw
4. Bending: Servomotor bending with reducer; accuracy ± 0.05°.
5. Premium hydraulic part with professional hydraulic system design.
6. Automatic lubrication system for moving areas.
7. Self-diagnostic system, detecting the error immediately.
8. Multiple groups pipe-bending information storage;
9. Industrial PC (windows system) assorted with touch screen display, 3D preview, remote control, D bending simulation, collision prevention.
10. Electric cabinet cooling fan and the hydraulic cooling system ensure the equipment long-time work stably under the high temperature.
