STB-38CNC-4A-3S Mandrel Tube Bending Machine Three-Stack Tooling For Sale

STB-38CNC-4A-3S Mandrel Tube Bending Machine Three-Stack Tooling

Home > PRODUCTS > Bending Solution > CNC Hybrid Pipe Bender > STB-38CNC-4A-3S Mandrel Tube Bending Machine Three-Stack Tooling

STB-38CNC-4A-3S Mandrel Tube Bending Machine Three-Stack Tooling

Quality STB-38CNC-4A-3S Mandrel Tube Bending Machine Three-Stack Tooling manufacturers & exporter - buy STB-38CNC-4A-3S Mandrel Tube Bending Machine Three-Stack Tooling from China manufacturer.

Share This Product:

Description
Parameters
Application
Video

1. Bend-arm (C-axis) by AC servomotor.
2. Clamp die by hydraulic; pressure die by hydraulic.
3. Carriage (Y-axis) by AC servomotor.
4. With rear booster driven by AC servomotor.
5. Collets (B-axis): rotation by AC servomotor, grip by hydraulic.
6. With roll bending function (PUSH BENDING), can make big radius by rolling.
7. Tooling shift : motion up-down by hydraulic or AC servomotor with brake; left-right by AC servomotor.
8. PDA (pressure die assist): by hydraulic or AC servomotor.
9. Automatic moving parts lubrication.
10. Standing pedestal, serves emergency stop, double-hand startup and remote control.

11. Industrial PC (windows system) assorted with touch screen display, 3D preview, remote control, D bending simulation, collision prevention.

12. Optional: auto loading and unloading system.
